Orbea Wild M-Team Dual Suspension Electric Bike - MyO (Customise your bike!)
Customise this bike with Orbea MyO
Fully customise this bike by choosing your favourite colours, components, and give it a name. Order before January 31st and recieve your fully custom Orbea by the end of February.
For any enquiries, please call 03 9529 3752.
Customise your bikeDescription
Orbea Wild M-Team Dual Suspension Electric Bike - MyO (MyOrbea - Customise your bike!)
We have specially reserved one of the award winning Orbea Wild FS eMTB's. This bike is currently in Spain and waiting for your special flare! You can pre-Order this bike now, customise it with your own colours, change specification and have delivered in February. Click the link to the Orbea Wild FS M-Team model in large to design this amazing bike right now:
Introducing the Orbea Wild M-Team electric bike, engineered for mountain biking enthusiasts who demand peak performance. This premium electric bike features a powerful motor and lightweight frame, allowing you to tackle the toughest terrains with ease. Equipped with advanced suspension and high-quality components, the Wild M-Team ensures exceptional comfort and agility on every ride.
Roam further and ride longer with its durable battery, designed to keep up with your adventurous spirit. The sleek, modern design not only enhances performance but also turns heads on the trails. Elevate your mountain biking experience with the Orbea Wild M-Team electric bike and conquer every challenge in your path!
Features
-
170mm of Gravity-Tuned Suspension
Wild offers 170mm of travel front and back, with custom-tuned Fox Float X or Float X2 shocks and the 38 fork.
-
Mullet Ready
Whether you want maximum speed with 29" or to focus on fun with 27", Wild has you covered.
-
Modular Battery System
Wild comes with the 600Wh as standard. This lighter battery offers the ultimate in handling. For those looking for longer rides the 750Wh battery, and the 250Wh range extender are options via MyO.
-
Bosch CX Performance Motor
BOSCH's 85 Nm motor needs no introduction, with endless power and controlled responses. The updated motor gives more precise control, is quieter and lighter, and offers less pedal resistance.
-
OMR Carbon
High modulus, high-strength fibres, and advanced carbon manufacturing techniques let us use less carbon while maintaining strength and rigidity.
-
Fox 38 Fork
Full power eBikes need stiffer, more burly forks. Wild counts on the benchmark Fox 38.
Specification
Frameset |
|
Frame | Orbea Wild OMR 2025, 29" wheels, Concentric Boost 12x148 |
Shock | Fox Float X2 Factory Trunnion 2-Pos Adjust Kashima custom tune 205x65mm |
Fork | Fox 38 Float Factory 170 Grip X2 QR15x110 Kashima |
Steerer Tube | Alloy 1-1/2", Black Oxidated Bearing |
Electric Bike | |
Battery | Bosch Powertube 750Wh Horizontal BBP3770 |
Range Extender | N/A |
Motor | Bosch Performance Line CX BDU3840 |
Display | Bosch System Controller BRC3100 |
Charger | Bosch Charger 4A (230V) BPC3400 |
Remote | Bosch Mini Remote BRC3300 |
Drivetrain | |
Chainring | e*thirteen e*spec Direct Mount 34T Boost |
Crank | e*thirteen Plus Alloy |
Shifters | Shimano XT M8100 I-Spec EV |
Cassette | Shimano CS-M8100 10-51t 12-Speed |
Rear Derailleur | Shimano XT M8100 SGS Shadow Plus |
Chain | Shimano M8100 |
Chainguide | e*thirteen Plus Bosch CX Gen4 CL 55 32-36t |
Cockpit | |
Handlebar | OC Mountain Control MC10 Carbon, Rise 20, Width 800 |
Stem | OC Mountain Control MC11 Alu SL, 0º |
Computer Mount | OC Computer Mount CM-05, Garmin/Sigma |
Brakes | |
Brakes | Shimano XT M8120 Hydraulic Disc |
Rotors | Galfer Wave Rotors 203mm front / 203mm rear |
Brakes Configuration | N/A |
Wheels | |
Wheels | Oquo Mountain Control MC32TEAM POWER |
Tyres | Maxxis Minion 2.40" 120 TPI 3CT/DD/TR MaxxTerra |
Components | |
Seatpost | OC Mountain Control MC22, 31.6mm, Dropper |
Seatpost Lever | Shimano SL-MT500 I-Spec EV |
Saddle | Fizik Aidon 208x145mm manganese rail |
Grips | Ergon GE10 |
Accessories | |
Lights | N/A |
Sizing
S |
150 cm - 175 cm |
M | 160 cm - 185 cm |
L | 170 cm - 195 cm |
XL | 180 cm - 205 cm |
Geometry
S | M | L | XL | |
1. Seat Tube (C-T) |
415 | 415 | 435 | 450 |
2. Top Tube (EFF) | 563 | 586 | 612 | 639 |
3. Head Tube | 110 | 120 | 130 | 140 |
4. Chainstay | 448 | 448 | 448 | 448 |
5. BB Drop | 22 | 22 | 22 | 22 |
6. BB Height | 358 | 358 | 358 | 358 |
7. Wheelbase | 1228 | 1252 | 1285 | 1311 |
8. Head Angle | 63.5 | 63.5 | 63.5 | 63.5 |
9. Seat Angle | 77.5 | 77.5 | 77.5 | 77.5 |
10. Rake | 44 | 44 | 44 | 44 |
11. Standover | 730 | 730 | 730 | 730 |
12. Reach | 435 | 455 | 480 | 505 |
13. Stack | 625 | 634 | 643 | 652 |
14. Fork Length | 585 | 585 | 585 | 585 |
