Specification
| Description | |
|---|---|
| Frame | Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box |
| Colour | Blue Carbon View-Leo Orange (Custom Colourway) |
| Tyre Clearance | 45mm |
| Fork | Orbea Terra ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1 |
| Headset | FSA 1-1/2" Integrated Aluminium Cup |
| Crankset | Shimano GRX RX820 31x48t |
| Shifters | Shimano GRX Di2 RX825 |
| Cassette | Shimano Ultegra R8100 11-34t 12-Speed |
| Rear Derailleur | Shimano GRX Di2 RX825 |
| Front Derailleur | Shimano GRX Di2 RX825 |
| Chain | Shimano M7100 |
| Handlebar | Easton EC90 AX Carbon, flare 16º, Di2 internal routing |
| Stem | OC Road Performance RP10, -8º |
| Brakes | Shimano RX820 Hydraulic Disc |
| Wheels | Oquo Road Control RC25TEAM |
| Tyres | Pirelli Cinturato |
| Front Wheel Axle | Orbea Thru Axle 12x100mm M12x2 P1 Solid |
| Rear Wheel Axle | Orbea Thru Axle 12x142mm M12x2 P1 Solid inner threaded |
| Seatpost | OC Performance XP10 Carbon, 27.2mm, Setback 0 |
| Saddle | Prologo Akero AGX black rails size 155mm |
| Handlebar Tape | Orbea Anti-Slippery/Shock Proof |
Size Guide
What size do I need?
Wondering about the perfect bike size for you? We get it—finding the right fit can be tricky, especially with high-performance bikes. While it's tough to give precise advice without seeing you in person, our expert retailers are here to help. Whether you're looking for comfort, performance, or a bit of both, they'll guide you to the right size based on your goals and riding style. Don't leave it to guesswork— call into store or give us a call to start a conversation and make sure your new bike is just right for you.
| XS | SM | MD | LG | XL | ||
| Wheels | 700c | 700c | 700c | 700c | 700c | |
| Stack | 526 | 548 | 570 | 592 | 614 | |
| Reach | 375 | 382 | 389 | 395 | 402 | |
| Stack/Reach Ratio | 1.40 | 1.44 | 1.47 | 1.50 | 1.53 | |
| Top Tube Length | 526 | 539 | 558 | 570 | 590 | |
| Seat Tube Length | 405 | 438 | 471 | 504 | 537 | |
| Seat Tube Angle | 74.0 | 74.0 | 73.5 | 73.5 | 73.0 | |
| Head Tube Length | 110 | 131 | 152 | 178 | 199 | |
| Head Tube Angle | 70.0 | 70.5 | 71.0 | 71.0 | 71.5 | |
| BB Drop | 78 | 78 | 78 | 76 | 76 | |
| BB Height | 263 | 263 | 263 | 265 | 265 | |
| Front Center | 601 | 611 | 621 | 635 | 644 | |
| Chainstay Length | 420 | 420 | 420 | 420 | 420 | |
| Wheelbase | 1009 | 1019 | 1029 | 1044 | 1053 | |
| Rake | 55 | 55 | 55 | 55 | 55 | |
| Trail | 66 | 62 | 59 | 59 | 56 | |
| Standover Height | 713 | 746 | 768 | 798 | 825 |
What size do I need?
Wondering about the perfect bike size for you? We get it—finding the right fit can be tricky, especially with high-performance bikes. While it's tough to give precise advice without seeing you in person, our expert retailers are here to help. Whether you're looking for comfort, performance, or a bit of both, they'll guide you to the right size based on your goals and riding style. Don't leave it to guesswork—start a conversation with your local retailer today and make sure your new bike is just right for you.
MyO - Custom Orbea
Design Your Dream Ride with Orbea MYO at bikes.com.au
Ever wished your bike could be more than just another off-the-shelf ride? With Orbea MYO, it can be. Here at bikes.com.au, we’re offering you the chance to create something truly special—a bike that’s a perfect reflection of your style, your personality, and how you ride. Whether you're tearing up the tarmac, tackling off-road trails, or cruising around town, MYO lets you design a bike that feels 100% yours.
So, What’s Orbea MYO?
Orbea MYO is like the ultimate bike design studio. It’s not just about picking a color; it’s about building a bike that matches your vibe. You get to choose everything—paint job, graphics, even the components that make your bike tick. Road bikes, gravel grinders, mountain bikes, or e-bikes—it doesn’t matter. If Orbea makes it, you can personalize it.
How Does It Work?
It’s super easy and honestly, a lot of fun. Here’s how you get started:
-
Choose Your Bike: Start with the basics. Pick the Orbea bike model that suits your riding style—whether that’s a sleek road bike, a burly mountain machine, or an e-bike for some extra power.
-
Get Creative with Colours: This is where things get exciting. Fancy a sleek matte black? How about a bold neon green? You’ve got a massive palette to play with. Want your name on the frame? Go for it! The bike is your canvas.
-
Fine-Tune the Details: It’s not just about the looks. You can tweak your bike’s components to match how you ride. Whether you want lightweight wheels for extra speed or a dropper post for more control on the trails, you’ve got options.
-
Sit Back & Wait for Your Masterpiece: Once your design is done, Orbea’s team hand-builds it to your exact specs. All that’s left is to wait for it to arrive, then hit the road (or trail) with your one-of-a-kind ride.
Why Go Custom?
It’s simple: a bike that’s built just for you rides better. When you have a say in everything—from the way it looks to how it performs—you’re not just riding any old bike. You’re riding your bike. Plus, let's be honest, showing up with a custom bike makes you look pretty cool too.
Why Choose Orbea MYO at bikes.com.au?
At bikes.com.au, we’re not just selling bikes—we’re helping you create your dream ride. Our team knows Orbea inside out, and we’re here to help you through the whole process. Whether you need advice on choosing components or just want to chat about colour schemes, we’ve got your back.
Ready to Build Your Dream Bike?
Head over to our Orbea MYO customisation page and start designing. Whether you’re after something sleek for the road, rugged for the trails, or electrified for extra boost, we’ll help you create a bike that’s truly yours.
Because at the end of the day, your bike should be as unique as you are—and at bikes.com.au, that’s exactly what we’re here to make happen.
